Computer Controlled Corrugated Box Printing Machine With Remote Diagnosis

Ask Lasest Price
Price :	1800 USD
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	200 sets per year
Delivery Time :	35 days

Add to Cart

Product Details
Company Profile

Computer Controlled Corrugated Box Printing Machine With Remote Diagnosis

Automatic Carton Box Flexo Printing Die Cutting Slotting Machine For Carton Boxes

Product Description

FEATURES:

·This machine is designed and made to stringen specification and safety standard,with the advantages of high speed, auto control and quick order shift.

·Adopt high quality material and parts. All electronic components are with CE standard and safety standard can equal European.

·Every unit is fixed with vacuum suction transtem,able to shift order of the idle printing unit under production.

·Adopt the advanced Siemens Servo control system from Germany,auto tracking and responding to ensure long-term high printing precicion.

·Apply advanced electrostatic adherence,hair brush and roller brush combined dust collection system,achieve good dust removal effect and ensure perfect dot and solid printing result.

·Centralized computer control with memory of whole machine and able to save orders.

·Able to facilitate the production management.

·Equipped with remote diagnosis and maintaince function.

Model	900 * 2000	1200 * 2000
Max Mechanic Speed	300 pcs / min	280 pcs / min
Max Feeding Size	880 * 2000 mm	1180 * 2000 mm
Min Feeding Size	300 * 650 mm	350 * 750 mm
Skip Feeding	1100 * 2000 mm	1500 * 2000 mm
Max Printing Area	800 * 2000 mm	1150 * 2000 mm
Max Thickness of Board	7.2 mm	7.2 mm
Min Slotting Space	240 * 80 * 240 * 80 mm	250 * 90 * 250 * 90 mm
Max Slot Depth	250 mm	320 mm
Max Thickness of Board	12 mm	12 mm
Dimension (L * W * H)	111659 * 4240 * 3200 MM	13015 * 4400 * 3500 MM
