    2200mm 7 Ply Carton Box Stitching Machine Ce Certified

    Ask Lasest Price
    Brand Name : AODONG &LUM
    Model Number : 1200-2200
    Certification : CE SO9001
    Price : 1000
    Payment Terms : L/C, T/T
    Supply Ability : 5set/month
    Delivery Time : 30
    • Product Details
    • Company Profile

    2200mm 7 Ply Carton Box Stitching Machine Ce Certified


    2200mm 7 Ply Carton Box Stitching Machine Ce Certified


    Technical Parameter
    ModelAD-1200AD-1500AD-1800
    stapling speed280-300nail/min280-300nail/min280-300nail/min
    Stitching wire18#(1.8*0.8mm)18#(1.8*0.8mm)18#(1.8*0.8mm)
    Stitching thickness3/5/7 ply3/5/7 ply3/5/7 ply
    Length of strength arm1200mm1500mm1800mm
    Max Sheet size(C+D)1200mm1500mm1800mm
    Motor power1.5KW1.5KW1.5KW
    shape size1550*580*1950mm1850*580*1950mm2150*580*1950mm
    Machine weight400kg430kg460kg


    Functions:


    1, High-speed double servo can nail 420 nails per minute

    2, Double servo drive, accurate, mechanical transmission part reduced, thereby effectively reducing the rate of mechanical failureBack manual baffle or electric baffle (optional)

    3, Rear manual baffle or electric baffle (optional)

    4, Touch screen controls nail distance, nail number, nail seed, simple operation without experience

    5, Single nail, double nail and reinforcing nail can be nailed

    6, One minute size change

    7, Automatic counting of paper feeding Department (0-999). automatic delivery after bundling, convenient bundling

    8, Covered and uncovered boxes can be nailed (the shortest distance from the first nail to the edge of the carton is 25mm)

    9, Paper table rises automatically and keeps feeding table height all the time.

    10, Only two people to operate, reduce salaries
