    High Speed Automatic Flute Laminating Machine Roller Design Easy Cleaning

    Ask Lasest Price
    Brand Name : LUM
    Model Number : LUM-1800
    Certification : ISO9001
    Price : 35000-40000USD
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 45 sets per month
    Delivery Time : 35 days
    • Product Details
    • Company Profile

    High Speed Automatic Flute Laminating Machine Roller Design Easy Cleaning

    High Speed LUM - 1800 Automatic Flute Laminating Machine


    Model/LUM13001500160018002000 designed
    Max size of cover face130mmX1200mm1500mmX120mm1600mmX1200mm1800mmX1200mm
    Mix size of cover face350mmX350mm350mmX350mm350mmX350mm350mmX350mm
    Economic speed0-120pce/min0-120pce/min0-120pce/min0-120pce/min
    Laminating prcision±1±1±1±1
    Main power6KW6.5KW6.5KW6.5KW
    Dimension8.8mX1.95mX1.7m8.8mX1.95mX1.7m8.8mX1.95mX1.7m8.8mX1.95mX1.7m
    WeightAbout 3tAbout 3.5tAbout 3.5tAbout 4t

    Major feature:
    1 .The vacuum suction-type feeding system can lead the paper accurately into the machine; Cycle stacking planes could stack the next batch paper well in a state of non-stop working,more efficient.
    2. Bottom sheet use suction auto feeding, automatic tracking according to the face paper's speed.
    3. New concept front gauge location, position high accuracy, bottom sheet never pull ahead.
    4. Machine uses touch-screen/PLC/servo motor control system, circuit system is stable and could display the failure alarm automatically.
    5. Automatic gluing, and the glue can be used circulatory, avoid glue waste.
    6. Roller design scientifically,avoid glue fly out when the speed is high.
    7. Pressure rollers adopt one side adjustment, convenient and fast.
    8. Rocker controls wash roller's fluctuation, easy cleaning.
    9. Counter designs scientifically, easy recording the amount you have been worked.
