    2200mm Corrugated Carton Box Making Machine Computerized

    Ask Lasest Price
    Brand Name : Aodong
    Model Number : Aodong-13
    Certification : CE,ISO9001,BV,CE (in the application)
    Price : 20000USD
    Payment Terms : D/A, D/P, T/T, Western Union, MoneyGram, L/C
    Supply Ability : 20sets per year
    Delivery Time : 35 days
    • Product Details
    • Company Profile

    2200mm Corrugated Carton Box Making Machine Computerized

    2200mm 3 /5 /7 layer corrugated cardboard production line / corrugation paperboard making machine


    Aodong Series automatic 3/5/7 layers corrugated plant is designed to make all kinds of the corrugated boxes for the packages.According to the various demands of the uses,the heating resources can be used with electrical heating, oil heating and steam heating,etc. While the max.design speed can be set between 100m/min to 250m/min. The corrugated plant can be completely controlled by the computer and connected with the production line management system. So it is believed to be the best choices for all the corrugated machines


    ModelUnitLUM-2000LUM-2200LUM-24002600

    Design Speed


    Pcs/min100/150/200
    Economic SpeedPcs/min70-80/100-130/150-160
    Max.feeding sizemm950×2000950×2200950×24001300×24001300×2600
    Min.size of paperboardmm260×500260×500260×500260×500260×500
    Min. space of slottingObverse

    mm


    160×160×160×160160×160×160×160
    Reverse knife

    mm


    280×80×280×80280×80×280×80
    Max. depth of slotmm240240240300300
    Skip feeding sizemm1100×20001100×22001100×24001500×24001500×2600
    Max.printing areamm950×1800950×2000950×22001250×22001250×2400
    Plate Thicknessmm7.27.27.27.27.2



    If you want to more information ,please contact us .thank you !
