A Typical Set Of Paper Splicer In Corrugated Packaging Industry

A Typical Set Of Paper Splicer In Corrugated Packaging Industry

1 represents the original paper web,2 represents the new paper web,3 refers to the paper frame,4 refers to the adhesive roller,5 refers to the clamping rod,6 refers to the pressure roller, 7 refers to the cutter,8 refers to the brake rod, 10 refers to the zero-tail join.

The whole process of paper splicing can be simply summed up as:The old paper roll stops running, the brake bar is pressed down, the pressure roll is down,and the cutter cuts off the old paper.The old paper break joint is connected with the new paper with double-sided adhesive under the pressure of the brake roll.At the same time,the paper storage trolley provides the base paper to the corrugated line.After the paper splicing,the new paper roll began to rotate,and the paper cart gradually returns to the position of the maximum splicer. This kind of splicer called "Flying Splicer". Operators at the time thought that their manual paper splicing technology was higher than the rapid paper splicing.

But as far as performance is concerned, the rapid paper splicing is quite reliable. Modern paper splicer have an electronic tension control system that responds instantly.This means that it has two brake systems,one for rolls in process and one for new rolls. And paper tension control system, brake pad, knife,cutting pad,roller balance structure,chain and bearing lubrication degree have played very critical role to the operation of the equipment.Another characteristic of the modern splicer is that the whole process of paper splicing takes less time.Automatic splicer adopts artificial intelligence design, equipped

with digital tension control system and computer terminal, so the paper splicing is quite efficient, reliable and fast.

Although the procurement input cost is large, the automatic splicer can achieve zero-tail join, avoidunnecessary waste when paper splicing,reduce the downtime and quality problems of corrugated board production line,finally to effectively ensure stable high production speed and high quality of corrugated board.
