MAIN SPECIFICATION

Model: LUM-A/B/C 2000Type 5 Layer Corrugated Line

1.Manufacture width: 1800mm

2.Design speed: 150m/min Working speed: 100-120m/min

Note: The roll paper which is used to test the production speed should meet following requirements:

Grade: Min. B Moisture content: 11% ±2%

Face paper: 100~250g/m2 Liner paper: 100~150g/m2

Corrugated paper: 100- 200g/m2

3.Flute profiles: A,B,C ,E fluteas (per clients request)

4.Steam requirement:

Steam consumption:2500-3000kg/hr Max. Pressure:1.2Mpa

Air compressor pressure:0.8~1.1Mpa

5. Electricity: 380V, 50Hz,three-phase four wire type(also can do as per clients country electricity standard)

6. Equipment Occupation:the real data is according to the drawing

7. Equipment Direction:Left or Right transmission will be according to client's requirements.

8. Factory request size:specific length as to the foundation of drawing

Welcome to contact us Thanks ! email: sale01@aodongpack.com
